Super Drill EDM

The Super Drill EDM is a fast-hole electrical discharge machine built to drill high-precision holes in conductive materials, including very hard ones. It uses tubular electrodes to produce fine, deep holes quickly, making it the ideal solution for mold and die making, aerospace components, medical devices and other high-precision parts.

General Specifications

• Machine type: Fast Hole EDM drilling machine
• Control system: CNC with touchscreen
• Number of axes: 3 axes (X, Y and Z)
• Machining method: Electrical Discharge Machining (EDM)
• Compatible materials: Steel, stainless steel, carbide, titanium, aluminum, copper and other conductive materials.
• Drilling diameter: From 0.2 mm up to 3.0 mm (depending on configuration).
• Drilling depth: High depth-to-diameter ratio.
• Positioning accuracy: High precision for industrial applications.
• Drilling speed: High productivity on small, deep holes.
• Dielectric system: Deionized water with filtration and recirculation.
• Work table: Ready for workholding and accessories.
• Guarding: Safety enclosure with transparent doors for safe operation.
• Applications:
  • Start-hole drilling for wire EDM.
  • Cooling channels in molds.
  • Precision micro-drilling.
  • Mold and die making.
  • Aerospace, automotive and medical industries.

Advantages

• Drills hardened materials without inducing mechanical stress.
• High accuracy and excellent surface finish.
• Ideal for small-diameter, deep holes.
• Shortens production times.
• Intuitive CNC control for efficient operation.
• Low electrode wear and high repeatability.
